10 inch Full Face Gasket, 3565 Series Garlock, 1/16 inch Thickness, 12 bolt holes, Bolt Hole Diameter: 1.00 inch, Tempature range (F): 500 to -450, Pressure Class 150, Color: White, For Use With: Hydrocarbons, solvents, moderate concentrations of acids, Caustics, and Cryogenics, Gasket Compound Material: Microcellular PTFE, PTFE with Aluminosilicate Microspheres.
| Bolt Circle Diameter | : | 14.25 in |
| Bolt Hole Size | : | 1.00 in |
| Color | : | White |
| Compliances | : | FDA Compliant, REACH Compliant, RoHS Compliant |
| Inside Diameter | : | 10.75 in |
| Item Type | : | Gasket-Full Face |
| Material | : | Envelon |
| Nominal/Diameter Size | : | 10 in |
| Number of Bolt Holes | : | 12 |
| Outside Diameter | : | 16.00 in |
| Pressure Class | : | 150 lb |
| Pressure Rating | : | 1200 psi |
| Series | : | 3565 |
| Temperature Range | : | 500 to -450 deg f |
| Thickness | : | 1/16 in |
