Milwaukee Valve BA-100 A 34 VMBA1003/4
Milwaukee Valve BA-100 A 34 2-Piece Ball Valve With Handle, 3/4 in Nominal, FNPT End Style, Cast Bronze Body, Full Port, RPTFE Softgoods, Domestic
- Brand Name: Milwaukee Valve
- Manufacturers: Milwaukee Valve
- MKSPN: VMBA1003/4
- MPN: BA-100 A 34
- Min. Order Qty: 1
- Qty. Interval: 1
-
Availability:
-
Login or Register for pricing
Milwaukee Valve Ball Valve, 2-Piece, Series: BA-100, 3/4 in Nominal, FNPT End Style, 600 psi Pressure, Full Port, 0.76 in Orifice, Chrome Plated Brass Ball, 2.64 in L Inlet to Outlet, 2.08 in Top to Inlet Center, Cast Bronze, Brass Stem and RPTFE Seat Trim, RPTFE Softgoods, Domestic
| Actuator Type | : | Lever Handle |
| Ball Material | : | Chrome Plated Brass |
| Domestic/Import | : | Domestic |
| End Style | : | FNPT |
| Inlet to Outlet Length | : | 2.64 in |
| Item Type | : | Ball Valve-Threaded 2 Piece |
| Material | : | Brass/Bronze |
| Media | : | Non-Potable Water |
| Nominal/Diameter Size | : | 3/4 in |
| Orifice Size | : | 0.76 in |
| Port Type | : | Full |
| Pressure Rating | : | 600 psi |
| Series | : | BA-100 |
| Softgoods Material | : | RPTFE |
| Top to Inlet Center | : | 2.08 in |
| Trim Material | : | Brass Stem and RPTFE Seat |
| Type | : | 2-Piece |
Blow-out proof stem
