10 inch Full Face Gasket, SBR Red Rubber, 1/8 inch Thickness, 12 bolt holes, Bolt Hole Diameter: 1.00 inch, Tempature range (F): 180 to -20, Pressure Class 150, Color: Red, For Use With: Wide Range of Fluids, Excluding: Gasoline, Oil, Alkalis, and Acids
| Bolt Circle Diameter | : | 14.25 in |
| Bolt Hole Size | : | 1.00 in |
| Color | : | Red |
| Inside Diameter | : | 10.75 in |
| Item Type | : | Gasket-Full Face |
| Material | : | Red Rubber |
| Nominal/Diameter Size | : | 10 in |
| Number of Bolt Holes | : | 12 |
| Outside Diameter | : | 16.00 in |
| Pressure Class | : | 150 lb |
| Pressure Rating | : | 700 psi |
| Series | : | Red SBR Rubber |
| Temperature Range | : | 180 to -20 deg f |
| Thickness | : | 1/8 in |
