10 inch Spiral Wound Gasket, 316 Stainless Steel , 1/8 inch Thickness Compressed, Temperature range (F): 850 to -150, Pressure Class 150, Color Code: Green with Gray Stripe
| Color | : | Green with Gray Stripe |
| Compliances/Standards | : | REACH Complaint, RoHS Compliant |
| Filler Material | : | Flexible Graphite |
| Inner Ring Material | : | 316L Stainless Steel |
| Inside Diameter (Inner Ring) | : | 10.560 in |
| Inside Diameter (Outer Ring) | : | 12.500 in |
| Inside Seal Diameter | : | 11.310 in |
| Item Type | : | Gasket-Spiral Wound |
| Material | : | 316/316L Stainless Steel |
| Nominal/Diameter Size | : | 10 in |
| Outer Diameter (Outer Ring) | : | 13.380 in |
| Outer Ring Material | : | Carbon Steel |
| Outer Seal Diameter | : | 12.500 in |
| Pressure Class | : | 150 lb |
| Series | : | Spiral Wound |
| Temperature Range | : | 850 to -150 deg f |
| Thickness | : | 1/8 in |
| Type | : | Ring |
