304 Stainless Raised Face Socket Weld Flange 150lb Import
Raised Face Socket Weld Flange, 304/304L Stainless Steel, 150 lb, SCH 40S Bore, Import
| Compare (0) selected | Item | Properties | Quantity | Price / UOM | Availability |
|---|---|---|---|---|---|
|
W154SWR1/2 |
ItemType: Socket Weld Flange Nominal/DiameterSize: 1/2 in EndStyle: Socket Weld PressureClass: 150 lb Type: Raised Face Domestic/Import: Import Material: 304/304L Stainless Steel BoltCircleDiameter: 2.38 in LengthThroughHub: 0.56 in HubDiameter: 1.19 in Thickness: 0.38 in BoltHoleSize: 5/8 in NumberofBoltHoles: 4 OutsideDiameter: 3.50 in BoltSize: 1/2 in Approved Vendor Raised Face Socket Weld Flange, 1/2 in, 304/304L Stainless Steel, 150 lb, SCH 40S Bore, Import |
/
|
|
|
|
|
W154SWR3/4 |
ItemType: Socket Weld Flange Nominal/DiameterSize: 3/4 in EndStyle: Socket Weld PressureClass: 150 lb Type: Raised Face Domestic/Import: Import Material: 304/304L Stainless Steel BoltCircleDiameter: 2.75 in LengthThroughHub: 0.56 in HubDiameter: 1.50 in Thickness: 0.44 in BoltHoleSize: 5/8 in NumberofBoltHoles: 4 OutsideDiameter: 3.88 in BoltSize: 1/2 in Approved Vendor Raised Face Socket Weld Flange, 3/4 in, 304/304L Stainless Steel, 150 lb, SCH 40/STD Bore, Import |
/
|
|
|
|
|
W154SWR1 |
ItemType: Socket Weld Flange Nominal/DiameterSize: 1 in EndStyle: Socket Weld PressureClass: 150 lb Type: Raised Face Domestic/Import: Import Material: 304/304L Stainless Steel BoltCircleDiameter: 3.12 in LengthThroughHub: 0.62 in HubDiameter: 1.94 in Thickness: 0.50 in BoltHoleSize: 5/8 in NumberofBoltHoles: 4 OutsideDiameter: 4.25 in BoltSize: 1/2 in Approved Vendor Raised Face Socket Weld Flange, 1 in, 304/304L Stainless Steel, 150 lb, SCH 40S Bore, Import |
/
|
|
|
|
|
W154SWR11/2 |
ItemType: Socket Weld Flange Nominal/DiameterSize: 1-1/2 in EndStyle: Socket Weld PressureClass: 150 lb Type: Raised Face Domestic/Import: Import Material: 304/304L Stainless Steel BoltCircleDiameter: 3.88 in LengthThroughHub: 0.81 in HubDiameter: 2.56 in Thickness: 0.62 in BoltHoleSize: 5/8 in NumberofBoltHoles: 4 OutsideDiameter: 5.00 in BoltSize: 1/2 in Approved Vendor Raised Face Socket Weld Flange, 1-1/2 in, 304/304L Stainless Steel, 150 lb, SCH 40S Bore, Import |
/
|
|
|
|
|
W154SWR2 |
ItemType: Socket Weld Flange Nominal/DiameterSize: 2 in EndStyle: Socket Weld PressureClass: 150 lb Type: Raised Face Domestic/Import: Import Material: 304/304L Stainless Steel BoltCircleDiameter: 4.75 in LengthThroughHub: 0.94 in HubDiameter: 3.06 in Thickness: 0.69 in BoltHoleSize: 3/4 in NumberofBoltHoles: 4 OutsideDiameter: 6.00 in BoltSize: 5/8 in Approved Vendor Raised Face Socket Weld Flange, 2 in, 304/304L Stainless Steel, 150 lb, SCH 40S Bore, Import |
/
|
|
Socket Weld Flange, Raised Face, 1/2 in Nominal, 0.88 in Inside Dia, 3-1/2 in Outside Dia, 0.44 in Thickness, SCH 40S Bore, 2.38 in Bolt Circle, 4 Bolt Holes, 0.62 in, 150 lb, 1.19 in Hub Dia, 0.62 in Length Through Hub, 304/304L Stainless Steel, Import
| Bolt Circle Diameter | : | 2.38 in |
| Bolt Hole Size | : | 5/8 in |
| Bolt Size | : | 1/2 in |
| Domestic/Import | : | Import |
| End Style | : | Socket Weld |
| Hub Diameter | : | 1.19 in |
| Item Type | : | Socket Weld Flange |
| Length Through Hub | : | 0.56 in |
| Material | : | 304/304L Stainless Steel |
| Method Of Manufacture | : | Weld |
| Nominal/Diameter Size | : | 1/2 in |
| Number of Bolt Holes | : | 4 |
| Outside Diameter | : | 3.50 in |
| Pressure Class | : | 150 lb |
| Thickness | : | 0.38 in |
| Type | : | Raised Face |
Forged 304/304L stainless steel construction
