Carbon Steel Threaded Raised Face Flange 150lb Domestic
Raised Face Flange, Forged Carbon Steel, Thread Connection, 150 lb, Domestic
| Compare (0) selected | Item | Properties | Quantity | Price / UOM | Availability |
|---|---|---|---|---|---|
|
W15THR1/2 |
ItemType: Threaded Flange Nominal/DiameterSize: 1/2 in BoltSize: 1/2 in PressureClass: 150 lb Thickness: 0.38 in OutsideDiameter: 3.50 in HubDiameter: 1.19 in Finish: Green BoltHoleSize: 5/8 in EndStyle: FNPT BoltCircleDiameter: 2.38 in Material: Carbon Steel Domestic/Import: Domestic Type: Raised Face TemperatureRating: -20 to 100 deg F Approved Vendor P40665 Raised Face Flange, 1/2 in Nominal, Forged Carbon Steel, Thread Connection, 150 lb, Domestic |
/
|
|
|
|
|
W15THR3/4 |
ItemType: Threaded Flange Nominal/DiameterSize: 3/4 in BoltSize: 1/2 in PressureClass: 150 lb Thickness: 0.44 in OutsideDiameter: 3.88 in HubDiameter: 1.50 in Finish: Green BoltHoleSize: 5/8 in EndStyle: FNPT BoltCircleDiameter: 2.75 in Material: Carbon Steel Domestic/Import: Domestic Type: Raised Face TemperatureRating: -20 to 100 deg F Approved Vendor Raised Face Flange, 3/4 in Nominal, Forged Carbon Steel, Thread Connection, 150 lb, Domestic |
/
|
|
|
|
|
W15THR1 |
ItemType: Threaded Flange Nominal/DiameterSize: 1 in BoltSize: 1/2 in PressureClass: 150 lb Thickness: 1/2 in OutsideDiameter: 4.25 in HubDiameter: 1.94 in Finish: Green BoltHoleSize: 5/8 in EndStyle: FNPT BoltCircleDiameter: 3.12 in Material: Carbon Steel Domestic/Import: Domestic Type: Raised Face TemperatureRating: -20 to 100 deg F Approved Vendor Raised Face Flange, 1 in Nominal, Forged Carbon Steel, Thread Connection, 150 lb, Domestic |
/
|
|
|
|
|
W15THR11/4 |
ItemType: Threaded Flange Nominal/DiameterSize: 1-1/4 in BoltSize: 1/2 in PressureClass: 150 lb Thickness: 0.56 in OutsideDiameter: 4.62 in HubDiameter: 2.31 in Finish: Green BoltHoleSize: 5/8 in EndStyle: FNPT BoltCircleDiameter: 3.50 in Material: Carbon Steel Domestic/Import: Domestic Type: Raised Face TemperatureRating: -20 to 100 deg F Approved Vendor Raised Face Flange, 1-1/4 in Nominal, Forged Carbon Steel, Thread Connection, 150 lb, Domestic |
/
|
|
|
|
|
W15THR11/2 |
ItemType: Threaded Flange Nominal/DiameterSize: 1-1/2 in BoltSize: 1/2 in PressureClass: 150 lb Thickness: 0.62 in OutsideDiameter: 5.00 in HubDiameter: 2.56 in Finish: Green BoltHoleSize: 5/8 in EndStyle: FNPT BoltCircleDiameter: 3.88 in Material: Carbon Steel Domestic/Import: Domestic Type: Raised Face TemperatureRating: -20 to 100 deg F Approved Vendor Raised Face Flange, 1-1/2 in Nominal, Forged Carbon Steel, Thread Connection, 150 lb, Domestic |
/
|
|
|
|
|
W15THR2 |
ItemType: Threaded Flange Nominal/DiameterSize: 2 in BoltSize: 5/8 in PressureClass: 150 lb Thickness: 0.69 in OutsideDiameter: 6.00 in HubDiameter: 3.06 in Finish: Green BoltHoleSize: 3/4 in EndStyle: FNPT BoltCircleDiameter: 4.75 in Material: Carbon Steel Domestic/Import: Domestic Type: Raised Face TemperatureRating: -20 to 100 deg F Approved Vendor Raised Face Flange, 2 in Nominal, Forged Carbon Steel, Thread Connection, 150 lb, Domestic |
/
|
|
|
|
|
W15THR21/2 |
ItemType: Threaded Flange Nominal/DiameterSize: 2-1/2 in BoltSize: 5/8 in PressureClass: 150 lb Thickness: 0.81 in OutsideDiameter: 7.00 in HubDiameter: 3.56 in Finish: Green BoltHoleSize: 3/4 in EndStyle: FNPT BoltCircleDiameter: 5.50 in Material: Carbon Steel Domestic/Import: Domestic Type: Raised Face TemperatureRating: -20 to 100 deg F Approved Vendor Raised Face Flange, 2-1/2 in Nominal, Forged Carbon Steel, Thread Connection, 150 lb, Domestic |
/
|
|
|
|
|
W15THR3 |
ItemType: Threaded Flange Nominal/DiameterSize: 3 in BoltSize: 5/8 in PressureClass: 150 lb Thickness: 0.88 in OutsideDiameter: 7.50 in HubDiameter: 4.25 in Finish: Green BoltHoleSize: 3/4 in EndStyle: FNPT BoltCircleDiameter: 6.00 in Material: Carbon Steel Domestic/Import: Domestic Type: Raised Face TemperatureRating: -20 to 100 deg F Approved Vendor Raised Face Flange, 3 in Nominal, Forged Carbon Steel, Thread Connection, 150 lb, Domestic |
/
|
|
|
|
|
W15THR4 |
ItemType: Threaded Flange Nominal/DiameterSize: 4 in BoltSize: 5/8 in PressureClass: 150 lb Thickness: 0.88 in OutsideDiameter: 9.00 in HubDiameter: 5.31 in Finish: Green BoltHoleSize: 3/4 in EndStyle: FNPT BoltCircleDiameter: 7.50 in Material: Carbon Steel Domestic/Import: Domestic Type: Raised Face TemperatureRating: -20 to 100 deg F Approved Vendor Raised Face Flange, 4 in Nominal, Forged Carbon Steel, Thread Connection, 150 lb, Domestic |
/
|
|
|
|
|
W15THR5 |
ItemType: Threaded Flange Nominal/DiameterSize: 5 in BoltSize: 5/8 in PressureClass: 150 lb Thickness: 0.88 in OutsideDiameter: 10.00 in HubDiameter: 6.44 in Finish: Green BoltHoleSize: 3/4 in EndStyle: FNPT BoltCircleDiameter: 8.50 in Material: Carbon Steel Domestic/Import: Domestic Type: Raised Face TemperatureRating: -20 to 100 deg F Approved Vendor P354878 Raised Face Flange, 5 in Nominal, Forged Carbon Steel, Thread Connection, 150 lb, Domestic |
/
|
|
|
|
|
W15THR6 |
ItemType: Threaded Flange Nominal/DiameterSize: 6 in BoltSize: 5/8 in PressureClass: 150 lb Thickness: 0.94 in OutsideDiameter: 11.00 in HubDiameter: 7.56 in Finish: Green BoltHoleSize: 3/4 in EndStyle: FNPT BoltCircleDiameter: 9.50 in Material: Carbon Steel Domestic/Import: Domestic Type: Raised Face TemperatureRating: -20 to 100 deg F Approved Vendor Raised Face Flange, 6 in Nominal, Forged Carbon Steel, Thread Connection, 150 lb, Domestic |
/
|
|
Flange, Raised Face, 1/2 in Nominal, 0.38 in Thickness, Thread Connection, 3-1/2 in OD, 150 lb Pressure Class, 1.19 in Diameter Hub, 0.56 in Length Through Hub, Forged Carbon Steel, Domestic
| Bolt Circle Diameter | : | 2.38 in |
| Bolt Hole Size | : | 5/8 in |
| Bolt Size | : | 1/2 in |
| Domestic/Import | : | Domestic |
| End Style | : | FNPT |
| Finish | : | Green |
| Hub Diameter | : | 1.19 in |
| Item Type | : | Threaded Flange |
| Length Through Hub | : | 0.56 in |
| Material | : | Carbon Steel |
| Method Of Manufacture | : | Weld |
| Nominal/Diameter Size | : | 1/2 in |
| Number of Bolt Holes | : | 4 |
| Outside Diameter | : | 3.50 in |
| Pressure Class | : | 150 lb |
| Temperature Rating | : | -20 to 100 deg F |
| Thickness | : | 0.38 in |
| Type | : | Raised Face |
