Warren Valve Check Valve, Swing TYPE, 3155C Series, Pressure Class: 150 lb, Raised Face Flanged End Style, 2 in Nominal/Diameter Size, Swing Item Type, Carbon Steel, Gear Actuator, Carbon Steel Trim, Graphite Softgoods
Warren Valve Check Valve, Swing TYPE, 3155C Series, Pressure Class: 150 lb, Raised Face Flanged End Style, 2 in Nominal/Diameter Size, Swing Item Type, Carbon Steel, Gear Actuator, Carbon Steel Trim, Graphite Softgoods
| Compare (0) selected | Item | Properties | Quantity | Price / UOM | Availability |
|---|---|---|---|---|---|
|
VW3155C82 |
ItemType: Swing Nominal/DiameterSize: 2 in Material: Carbon Steel EndStyle: Raised Face Flanged SoftgoodsMaterial: Graphite Type: Swing TrimMaterial: Carbon Steel PressureClass: 150 lb InlettoOutletLength: 8 in Series: 3155C Series Warren Valve 2V3155C-8R0G Warren Valve 3155C Series 2V3155C-8R0G Check Valve, 2 in, Raised Face Flanged End, Pressure Class: 150 lb, Carbon Steel |
/
|
|
|
|
|
VW3155C821/2 |
ItemType: Swing Nominal/DiameterSize: 2-1/2 in Material: Carbon Steel EndStyle: Raised Face Flanged SoftgoodsMaterial: Graphite Type: Swing TrimMaterial: Carbon Steel PressureClass: 150 lb InlettoOutletLength: 8-1/2 in Series: 3155C Series Warren Valve 2.5V3155C-8R0G Warren Valve 3155C Series 2.5V3155C-8R0G Check Valve, 2-1/2 in, Raised Face Flanged End, Pressure Class: 150 lb, Carbon Steel |
/
|
|
|
|
|
VW3155C83 |
ItemType: Swing Nominal/DiameterSize: 3 in Material: Carbon Steel EndStyle: Raised Face Flanged SoftgoodsMaterial: Graphite Type: Swing TrimMaterial: Carbon Steel PressureClass: 150 lb InlettoOutletLength: 9-1/2 in Series: 3155C Series Warren Valve 3V3155C-8R0G Warren Valve 3155C Series 3V3155C-8R0G Check Valve, 3 in, Raised Face Flanged End, Pressure Class: 150 lb, Carbon Steel |
/
|
|
|
|
|
VW3155C84 |
ItemType: Swing Nominal/DiameterSize: 4 in Material: Carbon Steel EndStyle: Raised Face Flanged SoftgoodsMaterial: Graphite Type: Swing TrimMaterial: Carbon Steel PressureClass: 150 lb InlettoOutletLength: 11-1/2 in Series: 3155C Series Warren Valve 4V3155C-8R0G Warren Valve 3155C Series 4V3155C-8R0G Check Valve, 4 in, Raised Face Flanged End, Pressure Class: 150 lb, Carbon Steel |
/
|
|
|
|
|
VW3155C86 |
ItemType: Swing Nominal/DiameterSize: 6 in Material: Carbon Steel EndStyle: Raised Face Flanged SoftgoodsMaterial: Graphite Type: Swing TrimMaterial: Carbon Steel PressureClass: 150 lb InlettoOutletLength: 14 in Series: 3155C Series Warren Valve 6V3155C-8R0G Warren Valve 3155C Series 6V3155C-8R0G Check Valve, 6 in, Raised Face Flanged End, Pressure Class: 150 lb, Carbon Steel |
/
|
|
|
|
|
VW3155C88 |
ItemType: Swing Nominal/DiameterSize: 8 in Material: Carbon Steel EndStyle: Raised Face Flanged SoftgoodsMaterial: Graphite Type: Swing TrimMaterial: Carbon Steel PressureClass: 150 lb InlettoOutletLength: 19-1/2 in Series: 3155C Series Warren Valve 8V3155C-8R0G Warren Valve 3155C Series 8V3155C-8R0G Check Valve, 8 in, Raised Face Flanged End, Pressure Class: 150 lb, Carbon Steel |
/
|
|
Warren Valve line of cast carbon steel check valves are offered in classes 150, 300, 600, 900 and 1500. For oil and gas refineries and petrochemical plants, Warren Valve cast carbon steel valves are an economical and quality choice. Warren valve are subject to rigorous quality inspections.
Warren Valve Check Valve, Swing TYPE, 3155C Series, 8-1/2 in Inlet to Outlet Length, Pressure Class: 150 lb, 5-3/4 in Top to Inlet Center, Raised Face Flanged End Style, 2-1/2 in Nominal/Diameter Size, Swing Item Type, Carbon Steel, Gear Actuator, Carbon Steel Trim, Graphite Softgoods
| Actuator Type | : | Gear |
| End Style | : | Raised Face Flanged |
| Inlet to Outlet Length | : | 8-1/2 in |
| Item Type | : | Swing |
| Material | : | Carbon Steel |
| Nominal/Diameter Size | : | 2-1/2 in |
| Pressure Class | : | 150 lb |
| Series | : | 3155C Series |
| Softgoods Material | : | Graphite |
| Top to Inlet Center | : | 5-3/4 in |
| Trim Material | : | Carbon Steel |
| Type | : | Swing |
- Bolted cover, exterior hinge pin, swing type disc
